The manufacturer cannot be held liable for any damage resulting from failure to follow the safety instructions and warnings.

Damage caused by incorrect connection, incorrect fitting, or incorrect use is not covered by the warranty.

Children shall not play with the appliance. Cleaning and user maintenance shall not be made by children without supervision.

NEVER try to extinguish a fire with water. Instead, switch the appliance off and then cover the flames with, for example, a lid or a fire blanket.

If a drawer underneath the appliance is permitted (see the installation instructions), without an intermediate bottom, this should not be used to store highly flammable objects/materials. Ensure that there is adequate clearance of a few centimetres between the bottom of the hob and the contents of any drawers.

Always provide adequate ventilation!

The hob is only to be used for the preparation of food.

This appliance is only designed for household use.

The appliance is not designed for heating rooms.

Never cover the appliance with a cloth or something similar. If the appliance is still hot or is switched on, there is a risk of fire.

Do not use the appliance as a worktop. The appliance may accidentally be switched on or still be hot, which means objects could melt, become hot or catch fire.

The appliance is not intended to be operated by means of an external timer or separate remote control system.

Never use a steam cleaner for cleaning the appliance. Only clean the appliance when switched off. The steam of a steam cleaner could reach the conducting parts and cause an electrical short.

The ceramic top is extremely strong but not unbreakable. For example, a spice jar or sharp utensil falling on it could cause it to break.

If you decide to discontinue using the appliance because of a fault, we recommend you cut off the cable after removing the plug from the plug socket. Take the appliance to your municipality’s waste disposal site.

WARNING: If the surface is cracked, switch off the appliance to avoid the possibility of electric shock.

The cooking zones heat up during use and stay hot for a while afterwards. Keep young children away from the hob during and immediately after cooking.

• Metal objects or objects containing metal, such as knives, forks, spoons, and lids, should not be placed on the hob surface, as they can get hot.

• When the induction hob is in use, keep objects that are sensitive to magnetic fields (credit cards, bank cards, discs, watches and similar items) away from the hob. We advise anyone with a pacemaker to consult their cardiologist first.

• Never use aluminium foil for cooking, and never place products packaged in aluminium on the hob. The aluminium would melt and irreparably damage your device.

• The hob is fitted with a cooling fan which cools the electronic components during cooking. The fan may operate for a while, even after the end of the cooking process.

• The induction cooking hob is also fitted with an overheating protector which protects the electronic components from damage. The protector operates in several ways. When the cooking zone temperature gets very high, the cooking power is automatically reduced. If this does not suffice, the cooking zone power continues to decrease, until the safety mechanisms switch off the cooking zone completely. When the cooking hob is cooled down, its total power will be available again.

This feature allows you to recall all the settings of the cooking zones if the hob was accidentally switched off.

The hob should be switched on again within 6 seconds. Pressing the Pause/Start key within 6 seconds will recall all settings before the appliance was last switched off.

If you remove the pan from an active cooking zone and within 6 seconds place it on a different cooking zone, you can transfer all the timer and cooking-related settings to the new cooking zone by touching the cooking zone key of the new cooking zone. To indicate this possibility, the new cooking zone displays copied settings on the slider. When the confirmation is done, the previous cooking zone is deactivated.

In induction cooking, only the zone on which the pan is placed is used. If you use a small pan on a large zone, the zone will adjust the power to the pan's diameter. The power will thus be lower, and it will take longer before the food comes to a boil.

• The touch sensors only react to the light pressure of a fingertip. Do not operate the controls with any other objects.

• The cooking hob is operated by a slider. You can either touch the selected part of the slider or move over the slider to increase or decrease the power.

• To set the cooking zone power level, touch the desired spot on the slider. As you touch the slider, the selected power level will appear on the cooking zone display unit.

• Do not use any objects to operate the slider.

The electronic controls are accurate and easy to set. On the lowest setting, you can melt chocolate directly in the pan, for example, or cook ingredients that you would normally heat in au bain-marie.

Thanks to the induction hob high power levels, bringing food to a boil is very quick.

The hob is easy to clean. Because the cooking zones do not get any hotter than the pans themselves, food spills are unlikely to burn into the glass.

The heat is generated in the pan itself. The glass top does not get any hotter than the pan. This means that the cooking zone is considerably cooler than a ceramic hob, for example.

Once a pan has been removed, the cooking zone cools down quickly.

Depending on the hob model, the cooking zones can affect each other. When several cooking zones are switched on simultaneously, the available capacity is shared automatically between them.

When the maximum capacity of the combination of cooking levels is reached during setting, one or more zones are automatically reduced to the highest possible setting at that moment. This is indicated by the flashing of the relevant control element.

You can use the ‘boost’ function for cooking at the highest power level during a short time (max. 10 minutes). After the maximum boost time has passed, the power will be reduced to setting 12.

1. Place a pan on a cooking zone.

2. Touch level 12 of the slider or slide along level 12 to set the boost level. Touch level 12 twice if 'Auto Boost' is off (refer to chapter 'Settings').



   • 1x scrolling text "booSt" and then "12b" appear in the display.

3. To deactivate the boost for the selected cooking zone, again touch level 12 on the slider.

1. Place a large pan on both cooking zones so that both zones are well covered.

   • The zones are linked automatically if the brd (auto-connecting) function is active (consult chapter ‘Settings’).

2. Touch simultaneously the cooking zone keys of the front and rear cooking zones.



   • The power level or temperatures are displayed simultaneously on both linked cooking zones.

3. Use the slider of the front cooking zone to set the desired cooking setting for the linked cooking zones.

4. Touch both cooking zone keys again to unlink the cooking zones.

Temperature (°C)	Use
45	melt chocolate
70	heating up/keeping warm
94	simmer vegetables
100	bring food or liquid to the boil quickly

Temperature (°C)	Use
140 / 160	fish, bacon, fried egg, vegetables in butter
180 / 200	schnitzel, sausages, jacket potatoes
220	wok

Temperature (°C)	Use
140 / 160	fish, bacon, fried egg, vegetables in butter
180 / 200	schnitzel, sausages, jacket potatoes
220	wok

At least one cooking zone must be active.

1. Touch the pause/start key.



   • You will hear a short beep.

   • The settings on all active cooking zones are reduced to setting 1 to keep food warm.

   • All timer functions are paused.

   • The pause key and slider flash.

   • All keys are inactive except the pause and on/off-key.

If no key is touched within 10 minutes, all active hobs automatically turn off.

1. Touch the pause/start key again within 10 minutes.

   • The hob continues to operate with the same settings.

Every cooking zone has a cooking zone timer.

The cooking zone timer can be used in two different ways: as a stopwatch timer or a switch-off timer that switches off the corresponding zone. The timers cannot be used at the same time.

• The stopwatch timer can be used to check how long cooking has been done on a cooking zone.

  • Touch the cooking zone timer button to select the stopwatch timer. After a short delay, it starts counting.

  • If ‘Auto-Stopwatch Timer’ is on, the stopwatch timer will start counting immediately when a power level is set. The current value will not be visible until the stopwatch timer is selected.

  • If ‘Auto-Stopwatch Timer’ is off, the stopwatch timer will start counting after selecting it.

  • Switch off the ‘Auto-Stopwatch timer’ by touching the cooking zone timer key and then touching the key again for a long time. Touching the cooking zone timer key for a long time afterwards sets the stopwatch timer to 0.00.

• The switch-off timer can be used to automatically switch off a cooking zone.

  • When the time set on the timer expires, the cooking zone will automatically switch off and emit an audible signal.

  • Touch the timer to turn off the audible signal; otherwise, it will turn off automatically after a while. The timer can be set separately for all cooking zones.

Setting the switch-off timer

1. Touch the timer key of the desired active cooking zone.



   • The timer key and '0.00' will flash on the cooking zone display unit.

2. Set the desired cooking time with the slider (see chapter 'Dynamic Slide').



3. If desired, repeat the same steps to set the timer for another active cooking zone.

   • After the set time has elapsed, the alarm sounds, the key for the relevant cooking zone flashes and ‘0.00’ flashes on the timer display.

   • The cooking zone is switched off.

   • To stop the alarm, touch the timer key, or remove the pan from the cooking zone.

Deactivating the cooking zone timer

1. Long touch the cooking zone timer key of the desired active cooking zone.

   • The timer is switched off.

The kitchen timer is not connected to a cooking zone. The kitchen timer does not switch off the cooking zone.

1. Touch the kitchen timer key.



   • Set a kitchen time using the slider.

   • The kitchen timer can be reset by touching the kitchen timer key for 3 seconds.

1. Touch the fan key to turn on the fan.



2. Touch the slider to set an extraction setting.



   Depending on the hood model, the extraction level can be set between setting 1 to 4 or 5 .

3. To switch off the cooker hood, press and hold the ‘Fan’ key for 1 second.

1. Touch the lighting key.



   • The light switches on at maximum strength.

2. Long touch the lighting key to set the lighting strength.

3. Short touch the lighting key to turn off the light.

The extraction module has three automatic extraction settings (see chapter ‘Settings’):

• Synchro Start (Settings)

  This setting allows the induction hob to automatically activate the lights of the connected hood every time the induction hob is turned on. Depending on the value you set, the ventilation will automatically start at that speed level when any cooking zone is activated.

• Synchro Control (Settings)

  In addition to Synchro Start, the hood will be controlled automatically depending on the current highest activated cooking level.

• Synchro Stop (Settings)

  The lights will be switched off together with the hob and the fan will, when all cooking zones have cooled down, also be switched off.

ConnectLife is a smart home platform that connects people, devices, and services. The ConnectLife application includes advanced digital services and carefree solutions that allow users to monitor and control appliances, receive notifications from a smartphone, and update software (supported features vary depending on your appliance and your region/country).

To connect your smart device, you need a home Wi-Fi network (only 2.4 GHz networks are supported) and a smartphone with the application ConnectLife.

To download the ConnectLife application, scan the QR code or search for ConnectLife in your favorite app store.

Your smart device's Bluetooth is turned on.

Do you have more questions? Visit us at www.connectlife.io or contact us at hello@connectlife.io.

• Make sure you know the name/SSID of your router’s Wi-Fi network and its password

  NOTE: only 2,4 Ghz networks are supported

  .

  NOTE: only 2,4 Ghz networks are supported

• Your smart device's Bluetooth is turned on.

Activate Wi-Fi to enable the Wi-Fi menu. The hob must be switched on.

1. Touch the Wi-Fi key for 5 seconds to open the Wi-Fi menu.

   • Depending on the Wi-Fi state, there are 1 to 3 options available in the menu: 'C’ (Connection) to set up a connection, 'P' (Pairing) to pair an additional user, and 'U’ (Unpairing) to unpair all users.

2. Use the slider to choose an option (if more than one option is available).

3. Touch the Wi-Fi key to confirm the selected option.

4. Touch the on/off key or touch the slider to close the menu.

   • If no key is pressed within 60 seconds, the menu will be switched off automatically.

1. Select option ‘Con’ in the Wi-Fi menu.

   • The appliance is in “Connection Setup Mode” for 5 minutes.

   • The Wi-Fi key flashes.

2. On the mobile app, start the process to ‘Add appliances’ and follow the instructions to set up the network.

This option requires that the connection setup has been performed successfully and the hob is connected to the cloud (Wi-Fi key is constantly full lit).

1. Select option ‘Pal’ in the Wi-Fi menu.

   • The appliance is in “Pairing Mode” for 3 minutes.

   • The Wi-Fi key flashes.

2. On the mobile app, start the process to ‘Add appliances’ and follow the instructions to pair the appliance.

This option requires that the connection setup has been performed successfully and the hob is connected to the cloud (Wi-Fi key is constantly full lit).

1. Touch the Wi-Fi key for 3 seconds.

2. Select option ‘Unp’ in the Wi-Fi menu to unpair all users and disconnect from the cloud.

   • The Wi-Fi key will flash 3 times.

   • The hob will delete all paired users ('Unpair').

1. Enter the Wi-Fi menu as explained in ‘Wi-Fi menu’.

2. Touch the Wi-Fi key for 2 seconds to deactivate Wi-Fi.

   • A short beep will be emitted. The Wi-Fi key will be off.

1. Switch off the hob.

2. Touch the on/off key for 5 seconds.

   • A short beep will be emitted. The Wi-Fi key will appear.

• Although food spills cannot burn into the glass, we nevertheless recommend you clean the hob immediately after use.

• For daily cleaning, a damp cloth with a mild cleaning agent is best.

• Dry off with kitchen paper or a dry tea towel.

• Stubborn stains can also be removed with a mild cleaning agent, washing-up liquid, for example.

• Remove water circles and limescale with cleaning vinegar.

• Traces of metals (caused by sliding pans) can be difficult to remove. Special products are available for this.

• Use a glass scraper to remove food spills. Melted plastic and sugar are also best removed with a glass scraper.

Symptom	Possible cause	Solution
Characters appear in the displays when the appliance is connected for the first time.	This is the standard set-up routine.	Normal operation.
The fan runs on for several minutes after the hob has been switched off.	The hob is cooling down.	Normal operation.
A slight smell is noticeable the first few times the hob is used.	The new appliance is heating up.	This is normal and disappears after the hob has been used a few times. Ventilate the kitchen.
You can hear a ticking sound in your hob.	This is caused by the capacity limiter on the front and back zones. A soft ticking sound can also occur at lower settings.	Normal operation.
Circle of pan bottom remains visible after cleaning.	Contaminated pan bottom used on the cooking zone.	Clean the induction hob with a ceramic hob cleaner and remove the dirt / grease from the pan bottom.
The pans make noise while cooking.	This is caused by the energy flowing from the hob to the saucepan.	This is normal for certain pans, particularly at high settings. This is not harmful to the pans or the hob.
You have switched a cooking zone on, but the display keeps flashing.	The pan you are using is not suitable for induction cooking or has a diameter of less than 12 cm.	Use a suitable pan (see chapter 'Pans for induction cooking').
A cooking zone suddenly stops working and you hear a signal.	The preset time has ended.	Switch off the signal by pressing the cooking zone key on the timer.
The hob is not working and nothing appears in the display.	There is no power supply due to a defective cable or a faulty connection.	Check the fuses or the electric switch (if there is no plug).
Zone stops unintended and residual heat indicator is shown.	Zone is overheated.	After the hob has cooled down, cooking can be continued.
A fuse blows when the hob is connected to the electrical power mains.	The appliance is incorrectly connected.	Check the electrical connections.
The ceramic glass plate broke.		Disconnect the device from the power supply. Contact your installer.
		Please note! Do not throw a broken ceramic glass plate in the glass recycling bin but take this to the Municipality's waste recycling centre.

Symptom	Possible cause	Solution
Error codes F0 to F7 and FC.	Defective generator.	Disconnect the device from the mains, wait 10 seconds and reconnect. Contact the technician if the error code does not disappear.
Error codes Fc	Appliance overheated.	Let the appliance cool down and start cooking again.
Error code FC02	The appliance has been connected incorrectly and/or the mains voltage is too high.	Have your connection changed.
Error codes Fc01, FC04, FC08 , FC10 and FH	Control panel error	Disconnect the device from the mains, wait 10 seconds and reconnect. Contact the technician if the error code does not disappear.
Error codes FJ	Mains voltage is too low.	Contact your energy supplier.
Error codes F9	Air circulation not good.	Make sure the venting holes under the cooking plate are open.
Other error codes.		Contact the service department.

Symptom	Possible cause	Solution
Wi-Fi icon not shown.	Wi-Fi turned off.	The hob must be switched off, then touch the on/off key and hold it for 5 seconds.
Wi-Fi setup failed.	Home network issues.	Check that your home network signal is strong and internet connection is working.
Home network is not displayed during the connection setup process.	The home network is not on 2.4 GHz, the network is hidden, or the signal strength is too weak.	Please check the network settings. Ensure a 2.4 GHz and visible network. If the signal is too weak, try to move the network router closer to the appliance.
Cooking hob is shown disconnected on the mobile app	Wi-Fi is disabled or home network issues.	Ensure that Wi-Fi is enabled, and the internet connection of your home network is working. Repeat the connection setup if necessary.
Other Wi-Fi problem.	Different causes.	First disable the Wi-Fi and enable it again. Check that the internet connection in your home network is working. Repeat the connection setup if necessary. Further troubleshooting available on www.connectlife.io or contact the service department.
Firmware update process failed.	Internet connection lost or power supply terminated.	Ensure the power supply is not terminated and a stable internet connection before retrying again. If failed again, contact the service department.

Error code	Symptom	Possible cause	Solution
E7	E7 appears on display after setting up the Wi-Fi connection.	Failed to connect to Wi-Fi network.	Try to connect the device to your network again. Make sure that new devices can connect to the network (e.g. MAC address filtering is disabled).

• This appliance must be earthed.

• The electrical connection must comply with national and local regulations.

• Prior to installation, ensure that the local distribution conditions (voltage and frequency) and the adjustment of the appliance are compatible.

• The voltage, frequency, power and the country for which the appliance has been designed are shown on the appliance rating plate.

• For class I appliances, check that your home’s electrical system provides proper earthing.

• The wall plug socket and plug should always be accessible.

• If a stationary appliance is not fitted with a supply cord and a plug, or with other means for disconnection from the supply mains having a contact separation in all poles that provide full disconnection under overvoltage category III conditions, the means for disconnection must be incorporated in the fixed wiring in accordance with the wiring rules. This is also applicable for appliances with a supply cord and plug when the plug is not accessible after installing the appliance. Using an omnipolar switch with a contact separation of at least 3 mm fitted in the fixed wiring will fulfil this requirement.

• The supply cord must hang freely and should not be fed through a drawer.

• For connecting, use an approved cable with the correct cable diameters appropriate for the connection. The cable casing should be made of rubber (preferably of the H05V2V2 or H07V2V2 type).

• Before connecting the appliance, make sure the voltage indicated on the rating plate conforms to the voltage in your power mains.

• The connection should be adjusted to the current and fuses.

• The appliance should not be connected to the mains via a multi-plug adapter or extension cable, as the safe use of the equipment cannot be guaranteed.

• After installation, the parts carrying electrical current and insulated parts shall be protected against contact.

• Disconnect the appliance from the mains supply before starting any repair work.

• Faulty parts may only be replaced by original parts. The manufacturer can only guarantee that original parts meet safety requirements.

Normal operation of the induction cooking hob electronic components requires sufficient air circulation.

The hob is fitted with a fan located in its lower part. If there is a drawer underneath the countertop, do not use it to store small objects or paper as these could, if sucked into the fan, damage the fan and the cooling system. Moreover, do not use the drawer to store aluminium foil or flammable substances or liquids (such as sprays). Keep such substances away from the cooking hob. Danger of explosion! There should be at least 20 mm of clearance between the contents of the drawer and the fan inlet vents.

	A (mm)	B (mm)	C (mm)	D (mm)
HI53xxx	380	520	50	46
HI56xxx	600	520	50	46
HI58xxx	800	520	50	46
HI59xxx	900	520	50	46

Cut-out in the worktop

	A (mm)	B (mm)	C (mm)	D (mm)	E (mm)
HI53xxx	340	Min. 600	490	Min. 40	Min. 60
HI56xxx	560	Min. 600	490	Min. 40	Min. 60
HI58xxx	750	Min. 600	490	Min. 40	Min. 60
HI59xxx	860	Min. 600	490	Min. 40	Min. 60

Cut-out in the worktop (flush)

	A1 (mm)	A2 (mm)	B (mm)	C1 (mm)	C2 (mm)	D (mm)	E (mm)
HI53xxx	384-385	340	Min. 600	524-525	490	Min. 40	Min. 60
HI56xxx	604-605	560	Min. 600	524-525	490	Min. 40	Min. 60
HI58xxx	804-805	750	Min. 600	524-525	490	Min. 40	Min. 60
HI59xxx	904-905	860	Min. 600	524-525	490	Min. 40	Min. 60

• Check the voltage. Before connecting the appliance, make sure the voltage specified on the rating plate conforms to the voltage of your power mains. The voltage of your power mains (220–240 V between L and N) should be checked by an expert using an appropriate measuring device.

• Check the voltages present as indicated in the diagrams below.

3 phases - 1 neutral	2 phases - 1 neutral	1 phase - 1 neutral

See chapter ‘Settings’, under Con - power limiter to set the parameter. This parameter must be set before placing a pan on the hob or activating a cooking zone.

Con - Current limiter

If your electrical wiring or circuit breakers do not meet the specified current draw on the rating plate, the current limiter can be activated by reducing the value of this setting. Doing so will cause a reduced performance of the induction hob.

The following numbering format of the setting is available: X.XX. The number left of the dot represents the number of connected phases, while the number right of the dot represents the electrical current per phase in Ampere.

While no pans are on any zone, touch any slider with two fingers and keep it pressed for 3 seconds. Different settings can now be toggled by using the slider. Select 'Con' and touch the slider for 3 seconds. Select the correct current limit value and touch the slider again for 3 seconds to confirm the setting.

Phase	IMax (A)	Grilling	Frying	Cooking	Simmer	Keep warm	Melting
3 Phases	16	x	x	x	x	x	x
	13	x	x	-	x	x	x
	10	-	-	-	x	x	x
	6	-	-	-	x	x	x
2 Phases (2 and 3 interconnected)	16	x	x	x	x	x	x
	13	x	x	-	x	x	x
	10	-	-	-	x	x	x
	6	-	-	-	x	x	x
1 Phase (1, 2 and 3 interconnected)	40	x	x	x	x	x	x
	35	x	x	x	x	x	x
	32	x	x	x	x	x	x
	25	x	x	x	x	x	x
	20	x	x	x	x	x	x
	16	x	x	x	x	x	x
	13	x	x	-	x	x	x
	10	-	-	-	x	x	x
	6	-	-	-	x	x	x

See the connection diagrams for the voltage between the phase and neutral conductors and voltage between the phase conductors.

Power cord core cross sectional area should be at least 1,5 mm² for the following power limiter settings which should be adjusted to your circuit breakers:

Power limiter configuration	Connection type	Power cord Type	Number and cross section of Power cord wires
3x16 A / 3x13 A / 3x10 A / 3x06 A	3 phases - 1 neutral	H05V2V2-F	5 x 1.5 mm²
2x16 A / 2x13 A / 2x10 A / 2x06 A	2 phases - 1 neutral	H05V2V2-F	4 x 1.5 mm²
2 x 16 A	2 phases - 2 neutral (only for NL)	H05V2V2-F	5 x 1.5 mm²
3 x 16 A	3 phases (only for BE)	H05V2V2-F	4 x 1.5 mm²
2 x 32 A	2 phases - 1 neutral	H05V2V2-F	4 x 4.0 mm²
1x32 A / 1x25 A	1 phase - 1 neutral	H05V2V2-F	3 x 4.0 mm²
1x20 A	1 phase - 1 neutral	H05V2V2-F	3 x 2.5 mm²
1x16 A	1 phase - 1 neutral	H05V2V2-F	3 x 1.5 mm²
